Description
For Numato Products Price details/ quotation please mail your requirements on dolphinlabs17@gmail.com
Mimas is an easy-to-use FPGA Development board featuring AMD Spartan-6 FPGA. Mimas is specially designed for experimenting and learning system design with FPGAs. This development board features AMD XC6SLX9 TQG144 FPGA with a maximum of 70 user IOs. The USB 2.0 interface provides fast and easy configuration download to the onboard SPI flash. You don’t need a programmer or special downloader cable to download the bitstream to the board.
Features
- FPGA: AMD Spartan-6 XC6SLX9 in TQG144 package
- Flash memory: 16 Mb SPI flash memory (M25P16)
- 100MHz CMOS oscillator
- USB 2.0 interface for On-board flash programming
- FPGA configuration via JTAG and USB
- 8 LEDs and four switches for user-defined purposes
- 70 IOs for user-defined purposes
- Onboard voltage regulators for single-power rail operation
Applications
- Product Prototype Development
- Signal Processing
- Wired and Wireless Communications
- Educational tool for schools and universities
