Description
For Numato Products Price details/ quotation please mail your requirements on dolphinlabs17@gmail.com
Styx is an easy-to-use Zynq Development Module featuring an AMD Zynq XC7Z020 chip with FTDI’s FT2232H Dual Channel USB Device. Zynq series of integrated circuits from AMD feature a hard System on Chip (SoC) with an ARM core and numerous peripherals including UART, SPI, I2C, Dual Gigabit Ethernet, SDIO, etc. Apart from the complete SoC, the Zynq also features an FPGA die equivalent to AMD Series-7 devices. It is specifically designed for the development and integration of FPGA based accelerated features into other larger designs.
Styx is pin-compatible with Pin compatible with Saturn S6 FPGA Module, Neso A7 FPGA Module, and Skoll K7 FPGA Module and thus offers a seamless upgrade path. The high-speed USB 2.0 interface provides fast and easy configuration download to the onboard SPI flash. No programmer or special downloader cable is needed to download the bitstream to the board. The second FTDI channel can be used to develop custom high-data-rate USB-based applications. Styx provides users flexibility in adding their peripherals through IO Expansion Headers.
Features
- Pin compatible with Saturn S6 FPGA Module, Neso A7 FPGA Module and Skoll K7 FPGA Module and offers a seamless upgrade path
- Device: XC7Z020 in CLG484 package
- DDR3: 2Gb DDR3
- Flash memory: 128 Mb Quad bit SPI flash memory
- 33.33 MHz CMOS Oscillator, 100 MHz CMOS Oscillator
- High-Speed USB 2.0 interface for onboard flash programming.
- FT2232H Channel B is dedicated to SPI Flash /JTAG Programming. Channel A can be used for custom applications
- Maximum IOs for user-defined purposes
- FPGA – 150 IOs
- FT2232H – 8 IOs
Applications
- Product Prototype Development
- Development and testing of custom embedded processors
- Signal Processing
- Communication device development
- Educational tool for Schools and Universities
